KJZ快速混合制粒機─【佳發制粒干燥】

2023-01-17 佳發制粒干燥 0 百度一下

適合行業	混合設備
發布作者	佳發制粒干燥
最近更新	2023-01-17 15:57:46

概述：應用概述 General of applications★廣泛適用于醫藥、食品、化工、冶金、染料等行業進行粉體混合及濕法制粒。★It is widely used for pharmaceutical industry, foodstuff industry, chemical industry,

文章詳情

應用概述 General of applications

★廣泛適用于醫藥、食品、化工、冶金、染料等行業進行粉體混合及濕法制粒。

★It is widely used for pharmaceutical industry, foodstuff industry, chemical industry, powder metallurgy industry, dyestuff industry, etc.

for powder mixing , wet mixing and granulating.

設備特點 Features of equipment

★該機混合均勻，粘合劑用量少，粘合能力強。

★生產過程密閉無死角，制粒均勻、清洗方便，完全符合GMP要求。

★較臥式濕法具有更為合理的混合效果。

★Mixing uniformly, less amount of binder, strong adhering.

★The productive process is sealed and no dead corner, granulating uniform, easy to clean. It conforms to the requirements of GMP.

★Compared with horizontal cylinder granulating technique, its mixing effect is more reasonable.

項目 ltem	規格 Specification	10	100	200	400
原料容器容積 Container`s volume	L	10	100	200	400
工作容量 Working volume	L	6	65	130	275
攪拌速度 Mixing speed	rpm	430/660	170/255	155/193	106/160
攪拌功率 Power of mixing	kw	0.6/1.1	6.5/8	13/16	18/26
絞碎速度 Cutting speed	rpm	1410/2850	1400/2800	1500/3000	1500/3000
絞碎功率 Power of cutting	kw	0.6/1.5	2.4/3	4.5/5.5	5.5/7.5
主機尺寸 Installation size for reference	H1(mm)	360	1100	1200	1300
	H2(mm)	950	2100	2350	2650
	B(mm)	350	850	1050	1215
	L(mm)	1050	2400	2600	2780

所有參數僅作參考，視物料情況，本公司擁有變更權利，并不另行通知。

All datas are used for reference only. According to the condition of material, our factory has the right to change but not notice, pardon!

聯系方式：

公司名稱：常州市佳發制粒干燥設備有限公司?

聯系人：鄒經理

電話：13606122988

網址：http://www.jf-granulator.com

地址：江蘇省常州三河口工業園區
